JHEMCU GHF722AIO HD DJI 40A AIO Flight Controller Integrated 4in1 40A BLheli_S 2~6S ESC

Specifications:
Brand Name: JHEMCU
Model: GHF722AIO-HD
MCU: STM32F722/216MHz
MIU: ICM-42688-P / Gyro / Accel
OSD: AT7456E
Baro: YES
Blackbox: 8MB
Input Voltage: 2-6S Lipo(7.4-26V)
5V BEC: 5V/2.5A ±0.1V
10V BEC: NO
Receiver: ELRS(CRSF),TBS(CRSF),SBUS,IBUS,DSM2,DSMX
IIC: NO
USART: USART1/USART2/USART3/USART4/USART5/USART6
LED Strip: Support
Buzzer: Support 5V Active
USER1 model: Support,with PINIO pad output
Current Port: YES
ESC Signal: PWM, Oneshot42, Oneshot125, Multishot, Dshot150, Dshot300, Dshot600
Voltage sensor: YES
DFU button: YES
USB: Micro USB
Firmware: Betaflight -4.43 JHEF7DUAL.HEX
Size: 33*33mm
Mounting holes: 25.5-26.5*3mm
Weight: 7.6g
ESC Current: 40A(MAX 45A)
MCU: EFM8BB21F16G
Type: Bluejay / BLHELI-S
ESC Firmware: Bluejay G-H-30-48-v0.16.hex
Whether to support 48K/96K firmware: Support


Package Included:
GHF722AIO-HD x1
XT60-H x1
M2x6.5mm Anti-vibration Ball x4
TVS board x1
14AWG Power Cable x2
1000UF/35V Electrolytic capacitor x1
